2009 Mercedes-Benz E-Class

2009 Mercedes-Benz E-Class Pictures & Specifications
Home » Mercedes-Benz

Picture Gallery

Technical Specifications

Make: Mercedes-Benz
Model: E 500
Engine: 5.5-litre V8
Aspiration: Natural
Maximum Power: 285 kW (388 hp) @ 6000 rpm
Maximum Torque: 530 Nm (391 lb-ft) @ 2800 rpm
Transmission: Seven-speed automatic
Drivetrain: Rear-wheel drive or optional all-wheel drive

2009 Mercedes-Benz E-Class

Daimler Press Release
11 January 2009

With three completely newly developed four-cylinder engines, the E-Class also remains one generation ahead where diesel technology is concerned. These engines feature latest-generation common-rail direct injection, fast piezo-electric injectors, improved exhaust gas recirculation and an innovative twin turbocharger, making for fast responsiveness and good performance characteristics. To express this in figures, the E 250 CDI with 150 kW (204 hp) and 500 Nm develops a 25 percent higher torque than the previous V6 diesel engine, but uses around 23 percent less fuel at only 5.3 litres per 100 kilometres (combined NEDC consumption). This corresponds to 139 grams of CO2per kilometre.

The new four-cylinder diesel engine also powers the E 220 CDI with 125 kW (170 hp) and the E 200 CDI with 100 kW (136 hp), also with a fuel consumption of only 5.3 litres per 100 kilometres.

The top model in the new E-Class diesel range is the six-cylinder E 350 CDI with an output of 170 kW (231 hp), which uses 0.5 litres per 100 kilometres less fuel than the previous E 320 CDI. From autumn 2009 the V6 diesel will also be available as a BlueTEC model with the world’s best emission control technology. The E 350 BlueTEC develops 155 kW (211 hp) and meets the EU6 exhaust emission standards planned for 2014. All the other engine variants in the new E-Class meet the EU5 limits.

The E 200 CGI and E 250 CGI are equipped with the newly developed four-cylinder direct-injection engine with a displacement of 1.8 litres, turbocharging and variable intake and exhaust camshafts. The E 200 CGI with 135 kW (184 hp) is equipped with a six-speed manual transmission and the ECO start/stop function as standard, and consumes only 6.8 litres of premium petrol per 100 kilometres (combined NEDC consumption, provisional figure). This equates to 159 grams of CO2per kilometre.

In the E 250 CGI with 150 kW (204 hp), which has a five-speed automatic transmission as standard, maximum torque is now 310 Nm, which represents an increase of more than 26 percent over the previous V6-engine. At the same time the NEDC fuel consumption is reduced by over 20 percent to 7.4 litres per 100 kilometres, equating to 175 grams of CO2per kilometre (provisional figures).

As before, the E 350 CGI with direct petrol injection with 215 kW (292 hp) and the top-of-the-line E 500 with 285 kW (388 hp) are included in the range of engine variants in the new E-Class. Detailed improvements have reduced the fuel consumption of these V6/V8 models by up to 0.6 litres per 100 kilometres. As a product from Mercedes-AMG, the new high-performance E 63 AMG develops 386 kW (525 hp).

The V6 and V8 models are equipped with a seven-speed automatic transmission and steering wheel selector lever as standard.

On request the V6 models E 350 CDI and E 350, as well as the eight-cylinder E 500, are available with latest-generation Mercedes all-wheel drive. This system distinguishes itself from previous all-wheel drive technology with greater efficiency, lower weight and more compact construction. These advantages produce noticeably better traction and fuel savings.
